Advantages
- Quick retrofitting between co and counterrotating
- Modular design and different applications
- Easy operability
- Different applications
- Modular screws for different mixing tasks
- Different screw length for high flexibility
Standard design
- With air cooling for a process temperature of up to 400°C
- With water cooling for a process temperature of up to 350°C
High-temperature design
- With air cooling for a process temperature of up to 500°C
- With water cooling for a process temperature of up to 450°C
Materials
- Polymers
- Thermoplasts
- Elastomers
- Special materials
- Highly filled materials
Application
- Mixing and dispersing of pigments
- Admixing of fillers and other additives into polymers
- Admixing of fibres (glass fibre, carbon fibre)
- Mixing of polymers or pastes
- Degassing of volatiles
- Continuous reaction extrusion
Control
The control is made via a touch screen CMI 17:
- Screen size 17 inch
- Display of all functions with set and actual values – tabularly, graphically or as bar diagram
- Large display of important process values
- Control button for all machine functions
- Possibility of recipe management
- Error and fault messages, language selection
- Ethernet connection
- Easy combination of the machines via Feldbus interface
- Possibility of the connection to the superior SCADA system (for lines in the pharmaceutical production)
Customers
- Raw material manufacturers
- Compounding and refining companies
- Processing companies
- Universities and institutes
- Pharmaceutical companies
- Companies in the medical sector
